safes—Locksmiths & Electronics in Tweed Heads NSW

YALE FIRE SAFE MEDIUM DOCUMENT SAFE

Like every Yale quality assured product, the new range of Yale Fire Safes has been designed with your peace of mind in focus. The entire range has been built and thoroughly tested to withstand intense heat and humidity, leaving your most precious document in good hands.

Yale Fire Safes for Documents protect your passports and all precious paper documents. These highly resistant safe-boxes guarantee a high level of fire resistance protection.

safes—Locksmiths & Electronics in Tweed Heads NSW

DESCRIPTION:

All Yale Fire Safes are equipped with a unique digital security keypad unlike any other on the market today. A scramble number input enables personal codes to be hidden within longer sequences of numbers, whilst additional access codes can be set for one-time use, ensuring privacy no matter who is in the room when accessing your safe. These state-of-the-art fire safes have been carefully designed to be worthy of your confidence and the Yale brand name.

STATE-OF-THE-ART DIGITAL TOUCHPAD

  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.
  • Time lock when wrong code is entered.
  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.
  • Time lock when wrong code is entered.

EASY TO OPERATE

  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.

PROTECTION

  • Tested to withstand up to one hour of intense fire.
  • 16mm steel locking bolts.
  • Hinges protected with 18mm steel dog-bolts.

External Dimensions

Internal Dimensions

Height

308mm
220mm

Width

410mm

330mm

Depth

342mm

225mm

Weight

26kg

Certified by SP (Swedish National Testing & Research Institute) and KS (Korea Standard)<
1-hour fire protection for documents. The internal temperature will not exceed 150degreesC in 927degreesC furnace.
Protects passports and other precious paper documents from fire.

DOWNLOADS

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

YALE DOCUMENT FIRE SAFE EXTRA LARGE

Like every Yale quality assured product, the new range of Yale Fire Safes has been designed with your peace of mind in focus. The entire range has been built and thoroughly tested to withstand intense heat and humidity, leaving your most precious document in good hands.

Yale Data Fire Safe are highly resistant safe-boxes guarantee a high level of fire resistance protection. They contain a “safe within a safe” insulation layer. This protects extra sensitive digital data, whether they are on an external hard-drive, CD-ROMs, DVDs or tapes.

safes—Locksmiths & Electronics in Tweed Heads NSW

Exterior dimensions: H 522mm x W 404 x D 440
Interior dimensions: H 410 mm x W 300 x D 300
Net weight: 53kg
Volume: 36.9 litres

Certified by SP (Swedish National Testing & Research Institute) and KS (Korea Standard).

1-hour fire protection for documents. The internal temperature will not exceed 150degreesC in 927degreesC furnace.

Protects passports and other precious paper documents from fire. All Yale Fire Safes are equipped with a unique digital security keypad unlike any other on the market today. A scramble number input enables personal codes to be hidden within longer sequences of numbers, whilst additional access codes can be set for one-time use, ensuring privacy no matter who is in the room when accessing your safe. These state-of-the-art fire safes have been carefully designed to be worthy of your confidence and the Yale brand name.

STATE-OF-THE-ART DIGITAL TOUCHPAD

  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Time lock when wrong code is entered.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.
  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Time lock when wrong code is entered.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.

EASY TO OPERATE

  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.
  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.

PROTECTION

  • Tested to withstand up to one hour of intense fire.
  • 16mm steel locking bolts.
  • Hinges protected with 18mm steel dog-bolts.
  • Tested to withstand up to one hour of intense fire.
  • 16mm steel locking bolts.
  • Hinges protected with 18mm steel dog-bolts.

DOWNLOADS

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

YALE FIRE SAFE LARGE DOCUMENT SAFE

Like every Yale quality assured product, the new range of Yale Fire Safes has been designed with your peace of mind in focus. The entire range has been built and thoroughly tested to withstand intense heat and humidity, leaving your most precious document in good hands.

Yale Fire Safes for Documents protect your passports and all precious paper documents. These highly resistant safe-boxes guarantee a high level of fire resistance protection.

DESCRIPTION:

  • All Yale Fire Safes are equipped with a unique digital security keypad unlike any other on the market today. A scramble number input enables personal codes to be hidden within longer sequences of numbers, whilst additional access codes can be set for one-time use, ensuring privacy no matter who is in the room when accessing your safe. These state-of-the-art fire safes have been carefully designed to be worthy of your confidence and the Yale brand name.

STATE-OF-THE-ART DIGITAL TOUCHPAD

  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.
  • Time lock when wrong code is entered.

EASY TO OPERATE

  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.

PROTECTION

  • Tested to withstand up to one hour of intense fire.
  • 16mm steel locking bolts.
  • Hinges protected with 18mm steel dog-bolts.

External Dimensions

Internal Dimensions

Height

420mm

320mm

Width

352mm

260mm

Depth

433mm
304mm

Weight

36kg

Certified by SP (Swedish National Testing & Research Institute) and KS (Korea Standard)<
1-hour fire protection for documents. The internal temperature will not exceed 150degreesC in 927degreesC furnace.
Protects passports and other precious paper documents from fire.

DOWNLOADS

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

YALE DATA FIRE SAFE LARGE

Like every Yale quality assured product, the new range of Yale Fire Safes has been designed with your peace of mind in focus. The entire range has been built and thoroughly tested to withstand intense heat and humidity, leaving your most precious document in good hands.

Two types of highly resistant safe-boxes guarantee a high level of fire resistance protection.

The Yale Fire Safes for Documents protects your passports and all precious paper documents. The Yale Data Fire Safe contains an additional “safe within a safe” insulation layer. This protects extra sensitive digital data, whether they are on an external hard-drive, CD-ROMs, DVDs or tapes.

safes—Locksmiths & Electronics in Tweed Heads NSW

Exterior dimensions: H 420mm x W 352 x D 433
Interior dimensions: H 224mm x W 157 x D 206
Net weight: 43kg
Volume: 7.2 litres

Certified by SP (Swedish National Testing & Research Institute) and KS (Korea Standard). 1-hour fire protection for data. The internal temperature will not exceed 50degreesC or 85% humidity in 927degreesC furnace.

Protects CDs, hard-drives and digital devices from fire. All Yale Fire Safes are equipped with a unique digital security keypad unlike any other on the market today. A scramble number input enables personal codes to be hidden within longer sequences of numbers, whilst additional access codes can be set for one time use, ensuring privacy no matter who is in the room when accessing your safe. These state-of-the-art fire safes have been carefully designed to be worthy of your confidence and the Yale brand name.

STATE-OF-THE-ART DIGITAL TOUCHPAD

  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Time lock when wrong code is entered.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.
  • Unique touchpad technology.
  • 1 billion+ digital user code.
  • Time lock when wrong code is entered.
  • Code scramble input function for privacy.
  • One-time access codes.
  • Silent input option.
  • 1-48 hours total lockdown mode.

EASY TO OPERATE

  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.
  • Re-settable 4-12 digital user code.
  • Low battery alarm signal.
  • Emergency battery capability.

PROTECTION

  • Tested to withstand up to one hour of intense fire.
  • Low battery alarm signal.
  • Hinges protected with 18mm steel dog-bolts.

DOWNLOADS

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

safes—Locksmiths & Electronics in Tweed Heads NSW

YALE CERTIFIED LAPTOP SAFE - YLM/200/EG1

FEATURES

  • Electronic lock with digital keypad.
  • Blue backlight display.
  • Laser cut steel door, with auto-opening function (when correct code is entered).
  • Reinforced steel hinge.
  • Brushed aluminium faceplate.
  • Concealed fixing points and mounting bolts included.
  • Interior finish with full felt lining.
  • Internal (LED) light source.
  • Armoured steel plates protecting locking mechanism.
  • Heavy-duty box packaging.
  • Electronic lock with digital keypad.
  • Blue backlight display.
  • Laser cut steel door, with auto-opening function (when correct code is entered).
  • Reinforced steel hinge.
  • Brushed aluminium faceplate.
  • Concealed fixing points and mounting bolts included.
  • Interior finish with full felt lining.
  • Internal (LED) light source.
  • Armoured steel plates protecting locking mechanism.
  • Heavy-duty box packaging.

External dimension H 200mm x W 480 x D 350
Internal dimension H 190mm x W 467 x D 280

  • 22mm diameter motorised locking bolts.
  • 6 lever double-bitted override locking system.
  • 2 original Yale override keys supplied.
  • 4 x AA size (1.5V each, total 6V) Panasonic batteries.
  • Pre-drilled holes with fixing bolts.
  • Certification – Sold Secure “Silver”, Secure by Design.
  • Full operating, installation instructions and fixing guide included.
  • 22mm diameter motorised locking bolts.
  • 6 lever double-bitted override locking system.
  • 2 original Yale override keys supplied.
  • 4 x AA size (1.5V each, total 6V) Panasonic batteries.
  • Pre-drilled holes with fixing bolts.
  • Certification – Sold Secure “Silver”, Secure by Design.
  • Full operating, installation instructions and fixing guide included.

DOWNLOADS

YALE CERTIFIED SAFE OFFICE - YSM/400/EG1

  • Electronic lock with digital keypad.
  • Blue backlight display.
  • Laser cut steel door, with auto-opening function (when correct code is entered).
  • Reinforced steel hinge.
  • Brushed aluminium faceplate.

External dimension H 400mm x W 350 x D 340
Internal dimension H 390mm x W 337 x D 270

  • Concealed fixing points and mounting bolts included.
  • Interior finish with full felt lining.
  • Internal (LED) light source.
  • Armoured steel plates protecting locking mechanism.
  • Heavy-duty box packaging.
safes—Locksmiths & Electronics in Tweed Heads NSW
  • Electronic lock with digital keypad.
  • Blue backlight display.
  • Laser cut steel door, with auto-opening function (when correct code is entered).
  • Reinforced steel hinge.
  • Brushed aluminium faceplate.
  • Concealed fixing points and mounting bolts included.
  • Interior finish with full felt lining.
  • Internal (LED) light source.
  • Armoured steel plates protecting locking mechanism.
  • Heavy-duty box packaging.

External dimension H 400mm x W 350 x D 340
Internal dimension H 390mm x W 337 x D 270

safes—Locksmiths & Electronics in Tweed Heads NSW
  • 22mm diameter motorised locking bolts.
  • 6 lever double-bitted override locking system.
  • 2 original Yale override keys supplied.
  • 4 x AA size (1.5V each, total 6V) Panasonic batteries.
  • Pre-drilled holes in body with fixing bolts.
  • Certification – Sold Secure “Silver”, Secure by Design.
  • Full operating, installation instructions and fixing guide included.
  • 22mm diameter motorised locking bolts.
  • 6 lever double-bitted override locking system.
  • 2 original Yale override keys supplied.
  • 4 x AA size (1.5V each, total 6V) Panasonic batteries.
  • Pre-drilled holes in body with fixing bolts.
  • Certification – Sold Secure “Silver”, Secure by Design.
  • Full operating, installation instructions and fixing guide included.

DOWNLOADS

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

CMI Homeguard Domestic Security Safe HG1

  • 7 Point locking 25mm diameter bolt work.
  • Expanding fire seal around doorframe.
  • Secondary relocking device.
  • Door (20kg) removes to aid handling.
  • Fully adjustable shelf.
  • Two 12mm boltholes in bottom.
  • Designed to give 1/2-hour fire protection.

Recommended overnight cash holding for all models $10,000.

External Dimensions

Internal Dimensions

Height

610mm

550mm

Width

410mm
340mm
Depth
340mm
240mm
Weight:
84kg

Add 50mm for handle.

Clear access 515mm x 320mm.

Border Locksmiths can supply safes Australia wide. Please call 1300 526 011 for shipping information and pricing.

safes—Locksmiths & Electronics in Tweed Heads NSW

CMI MINIGUARD DOMESTIC SECURITY SAFE

  • 2 x 40 x 12 Locking bolts with rear locking.
  • Expanding fire seal around doorframe.
  • All doors are interchangeable.
  • Door (12kg) removes to aid handling.
  • Removable shelf.
  • Two 12mm boltholes in bottom.
  • Designed to give 1/2-hour fire protection.
  • 2 x 40 x 12 Locking bolts with rear locking.
  • Expanding fire seal around doorframe.
  • All doors are interchangeable.
  • Door (12kg) removes to aid handling.
  • Removable shelf.
  • Two 12mm boltholes in bottom.
  • Designed to give 1/2-hour fire protection.

RECOMMENDED OVERNIGHT CASH HOLDING FOR ALL MODELS $10,000.

External Dimensions

Internal Dimensions

Height

300mm

240mm

Width

440mm

375mm

Depth

340mm

250mm

Weight

66kg
Close Menu
LOCKWOOD 929 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 949 EXTERIOR ESCAPE DEADLATCH

These locksets are produced from high purity zinc alloy and available in a comprehensive range of functions and attractive finishes.

FEATURES

  • Brass bolt with 13mm projection.
  • A brass rose is supplied to conceal inside fixing screws.
  • 70mm standard backset. 60mm backset also available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.
  • Successfully tested over a 4-hour period on fire door assemblies as specified in Australian Standard AS1905.1: 1990 Part 1 Fire Doors. Standard product has been tested for resistance level of up to 2 hours.

FUNCTION

  • Inside: Opened by knob at all times. Turnbutton locks or unlocks exterior knob.
  • Outside: Opened by handle when unlocked. Key locks or unlocks exterior handle but does not retract the bolt.

LEVERS AND ROSES

High purity zinc alloy. A rose cover is supplied to conceal internal fixing screws.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

70mm standard backset. 60mm and 127mm latches available separately.

LATCH

13mm projection.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

HANDING

Field adjustable handing.

FINISHES

Satin Chrome Brushed (SC)

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 929 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 929 EXTERIOR ESCAPE DEADLATCH

These locksets are produced from high purity zinc alloy and available in a comprehensive range of functions and attractive finishes.

FEATURES

  • Brass bolt with 13mm projection.
  • A brass rose is supplied to conceal inside fixing screws.
  • 70mm standard backset. 60mm backset also available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.
  • Successfully tested over a 4-hour period on fire door assemblies as specified in Australian Standard AS1905.1: 1990 Part 1 Fire Doors. Standard product has been tested for resistance level of up to 2 hours.

FUNCTION

  • Inside: Opened by knob at all times. Turnbutton locks or unlocks exterior knob.
  • Outside: Opened by handle when unlocked. Key locks or unlocks exterior handle but does not retract the bolt.

LEVERS AND ROSES

High purity zinc alloy. A rose cover is supplied to conceal internal fixing screws.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

70mm standard backset. 60mm and 127mm latches available separately.

LATCH

13mm projection.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

HANDING

Field adjustable handing.

FINISHES

Satin Chrome Brushed (SC)

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 538 STOREROOM ESCAPE SET

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob at all times.
  • Outside: Opened by key only. Knob is always rigid.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 536 ESCAPE SET

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob when unlocked. Turn-button locks both knobs.
  • Outside: Opened by knob when unlocked. Coin or screwdriver in emergency button unlocks both knobs but does not retract bolt.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 532 PRIVACY SET

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob when unlocked. Turn-button locks both knobs.
  • Outside: Opened by knob when unlocked. Coin or screwdriver in emergency button unlocks both knobs but does not retract bolt.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 532 PRIVACY SET

Designed as a non handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob when unlocked. Turn-button locks both knobs.
  • Outside: Opened by knob when unlocked. Coin or screwdriver in emergency button unlocks both knobs but does not retract bolt.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 531 PASSAGE SET

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection. 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob at all times.
  • Outside: Opened by knob at all times.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 530 ENTRANCE LOCKSET

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob at all times. Turnbutton locks or unlocks exterior knob.
  • Outside: Opened by knob when unlocked. Key locks or unlocks exterior knob but does not retract bolt.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

5-pin tumbler mechanism. Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 529 EXTERIOR ESCAPE DEADLATCH

Designed as a non-handed, easy to install lockset. This top quality range is suitable for residential and commercial applications including office partitioning.

FEATURES

  • Brass bolt with 13mm projection.
  • 60mm standard backset, 70mm and 127mm latches available.
  • Can be keyed alike, master keyed, grand master keyed, maison keyed or construction keyed.

FUNCTION

  • Inside: Opened by knob at all times. Turnbutton locks or unlocks exterior knob.
  • Outside: Opened by knob when unlocked. Key locks or unlocks exterior knob but does not retract bolt.

KNOB AND ROSES

High purity zinc alloy.

DOOR THICKNESS

32 to 48mm (all functions except 534 which suits doors 32 to 45mm).

BACKSET

60mm standard backset. 70mm and 127mm latches available separately.

LATCH

13mm projection brass bolt.

CYLINDER

5-pin tumbler mechanism. Brass cylinder and brass barrel.

FIRE RATING

Lockwood 530 Series Locksets have been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS1905.1:2005 Fire Resistant Doorsets.

HANDING

Non-handed lockset.

FINISHES

Satin Chrome Brushed (SC)

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9600 PANIC EXIT DEVICE WITH MORTICE LOCK 1200MM 127MM B

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9500 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

Standard maximum 838mm to suit (900mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9500 PANIC EXIT DEVICE WITH MORTICE LOCK 900MM 60MM B/S

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9500 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

Standard maximum 838mm to suit (900mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9500 PANIC EXIT DEVICE WITH MORTICE LOCK 900MM 89MM B/S

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9500 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

Standard maximum 838mm to suit (900mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9500 PANIC EXIT DEVICE WITH MORTICE LOCK 900MM 127MM B/

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9500 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

Standard maximum 838mm to suit (900mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9600 PANIC EXIT DEVICE WITH MORTICE LOCK 1200MM 89MM B/

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9600 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

1141 to suit (1200mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

DOWNLOADABLE CONTENT

LOCKWOOD 9600 PANIC EXIT DEVICE—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 9600 PANIC EXIT DEVICE WITH MORTICE LOCK 1200MM 89MM B/

Lockwood 9000 Series Panic Exit Devices are available in a range of functions. Mechanism design ensures easy installation, clean styling and ease of operation. Suitable for single or double doors.
The Lockwood 9600 Rim Type Panic Exit Device is specifically designed to be used in conjunction with the Lockwood 3572 High Security Cylinder Mortice Lock and Lockwood 1800/2800 Series Brass Door Furniture.
An additional benefit of this will enable the designer/specifier the convenience of using the same Lockwood brass lever/knob designs they select for the project.

OPERATION

  • Inside: “exit by” rim device operates mortice lock.
  • Outside: “entry by” lever/knob operates mortice lock.

FEATURES

  • Deadlatching on all bolts.
  • Safety clutch outside lever trim plate protects the unit from damage that could render the device inoperable.
  • Adjustable on site.
  • Automatic top and bottom latches maintaining the bolt drawn in when the door is open (vertical version).
  • Surface mounted for ease of installation.
  • Pick resistant bottom latch.

HANDING

All models are suitable for left-handed doors (L/H); each kit contains a conversion kit to change to right hand door (R/H) applications.

MATERIALS

  • The body is manufactured of steel.
  • Internal mechanisms made of steel or brass.
  • Main cover made of decorated electroplated steel pressing.
  • Secondary cover made of decorated Zamak.
  • Horizontal bar made of decorated steel.
  • Lever plate operating mechanism is made from electroplated steel pressings with high-density zinc alloy cover.

LATCHBOLT

Made of double chrome plated steel.

AUXILIARY BOLT

Made of double chrome-plated steel.

DOOR THICKNESS

  • Standard 35 to 45mm doors.
  • Extended spindle kit for up to 90mm doors.
  • Mortice lock version 32 to 48mm doors. Specify door thickness when other than standard.

PRODUCT WIDTH

1141 to suit (1200mm) door.

DOOR STILE

Suitable for both 90 and flush head door stiles minimum head clearance requirement of 30mm.

OUTSIDE TRIMS

  • Key entry, key entry with pull plate and key/lever entry with mechanism safety override.
  • Hold-back (dogging).
  • Euro cylinder key hold-back available on all types.
  • Hold-back is not an approved function on fire doors.

STANDARD FINISHES

  • Body – Silver, Powdercoat
  • Touchbar – Black, Powdercoat

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

DOWNLOADABLE CONTENT

LOCKWOOD 3572 VESTIBULE MORTICE LOCK—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 3573 SLIDING DOOR MORTICE LOCK

Suitable for heavy-duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels and similar buildings.
3570 Series Cylinder Mortice Locks are made from quality materials to meet high durability and strength requirements.
Various deadlocking functions operated generally by key outside and by turnknob or key inside. Locked by key or turnknob when door is closed.
For all sliding door deadlock functions specify primary lock (3573SC). This lock can then be easily adapted to suit function required.

FEATURES

BOLT

Deadlock.

FURNITURE

Compatible with all Lockwood cylinder escutcheons, turnknobs and plate furniture.

CASE AND COVER PLATES

  • High purity zinc alloy material cases and stainless steel cover plates.
  • Brass plates provided for plated finishes available in square and round end.

BACKSET

  • 60mm standard backset.
  • Extended backsets 89 and 127mm are available on application.

LATCHBOLTS

Latchbolts are 15mm, stainless steel. Deadlatching is achieved by an auxiliary stainless steel latchbolt. This auxiliary bolt retracts when the main latchbolt is withdrawn when the door is closed.

DEADBOLTS

Deadbolts are 19mm, stainless steel.

SPRINGS

High-grade spring steel material, corrosion protected.

CYLINDER RETAINING PIN

Hard-drawn spring steel wire, corrosion protected.

DOOR THICKNESS

32mm to 50mm locksets to suit thicker doors are available on application.

DOOR CLEARANCE

To ensure correct functioning of the deadlatching mechanism and security for all locks, the clearance between the door and the frame should be 3mm. However the deadlatching will operate up to 8mm door clearance.

ALUMINIUM DOORS

Aluminium door accessory packs and aluminium fix locks are available upon request. Specify SP3570-419 for mounting tabs accessory pack or 3572AFSC.

SECURITY

All 3570 Series Cylinder Mortice Locks conform to Level S2 (Physical Security) Australian Lock Standard (AS-4145.2-1993). Level S3 (Physical Security) is available upon request.

DURABILITY

All 3570 Series Cylinder Mortice Locks conform to level D3 (Durability) Australian Lock Standard (AS 4145.2- 1993).

FIRE RATING

Lockwood 3570 Series Mortice Locks have been successfully tested up to 4 hours (depending on type of door set) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

CYLINDER

  • 5-pin tumbler mechanism. Standard Lockwood oval shaped brass cylinders and brass barrels.
  • Functions require the use of different cams and adaptors.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

EXTENDED CYLINDERS

Extended cylinders are available for thicker doors.

REBATE

Rebate kits to suit 13mm standard rebate are available.

DOWNLOADABLE CONTENT

LOCKWOOD 3572 VESTIBULE MORTICE LOCK—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 3572 VESTIBULE MORTICE LOCK

Suitable for heavy-duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels, and similar buildings.
3570 Series Cylinder Mortice Locks are made from quality materials to meet high durability and strength requirements.
These locks have various latching functions, which can be operated by key or handle outside and by turnknob, key or handle inside.
For ease of selection specify primary lock (3572SC). This lock can then be easily adapted to suit function required.
These locks have various latching functions, which can be operated by key or by handle inside.

FEATURES

LATCH

Deadlatch only.

FURNITURE

Compatible with all Lockwood rose and plate furniture including Brass Door Furniture, Daintree, Aquileart, Artefact series II and Ovation Series.

CASE AND COVER PLATES

  • High purity zinc alloy material cases and stainless steel cover plates.
  • Brass plates provided for plated finishes available in square and round end.

BACKSET

  • 60mm standard backset.
  • Extended backsets 89 and 127mm are available on application.

LATCHBOLTS

Latchbolts are 15mm, stainless steel. Deadlatching is achieved by an auxiliary stainless steel latchbolt. This auxiliary bolt retracts when the main latchbolt is withdrawn when the door is closed.

DEADBOLTS

Deadbolts are 19mm, stainless steel.

SPRINGS

High-grade spring steel material, corrosion protected.

CYLINDER RETAINING PIN

Hard-drawn spring steel wire, corrosion protected.

DOOR THICKNESS

  • 32mm to 50mm
  • Locksets to suit thicker doors are available on application.

DOOR CLEARANCE

To ensure correct functioning of the deadlatching mechanism and security for all locks, the clearance between the door and the frame should be 3mm. However the deadlatching will operate up to 8mm door clearance.

ALUMINIUM DOORS

Aluminium door accessory packs and aluminium fix locks are available upon request. Specify SP3570-419 for mounting tabs accessory pack or 3572AFSC.

SECURITY

All 3570 Series Cylinder Mortice Locks conform to Level S2 (Physical Security) Australian Lock Standard (AS-4145.2-1993). Level S3 (Physical Security) is available upon request.

DURABILITY

All 3570 Series Cylinder Mortice Locks conform to level D3 (Durability) Australian Lock Standard (AS 4145.2- 1993).

FIRE RATING

Lockwood 3570 Series Mortice Locks have been successfully tested up to 4 hours (depending on type of door set) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

CYLINDER

  • 5-pin tumbler mechanism. Standard Lockwood oval shaped brass cylinders and brass barrels.
  • Functions require the use of different cams and adaptors.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

EXTENDED CYLINDERS

Extended cylinders are available for thicker doors.

REBATE

Rebate kits to suit 13mm standard rebate are available.

ELECTRIC STRIKES

Lockwood 3570 Series Mortice Locks are compatible with most electric strikes. Refer local sales office for further details.

DOWNLOADABLE CONTENT

LOCKWOOD 3577 DUAL ENTRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 3571 PRIMARY DEADLOCK

Suitable for heavy-duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels and similar buildings.
3570 Series Cylinder Mortice Locks are made from quality materials to meet high durability and strength requirements.
Various deadlocking functions operated generally by a key outside and by a turnknob or key inside. Locked by key or turnknob when the door is closed.
For all deadlock functions specify primary lock (3571SC). This lock can then be easily adapted to suit function required.

FEATURES

BOLT

19mm stainless steel bolt.

FURNITURE

Compatible with all Lockwood cylinder escutcheons, turnknobs and plate furniture.

CASE AND COVER PLATES

  • High purity zinc alloy material cases and stainless steel cover plates.
  • Brass plates provided for plated finishes available in square and round end.

BACKSET

  • 60mm standard backset.
  • Extended backsets 89 and 127mm are available on application.

LATCHBOLTS

Latchbolts are 15mm, stainless steel. Deadlatching is achieved by an auxiliary stainless steel latchbolt. This auxiliary bolt retracts when the main latchbolt is withdrawn when the door is closed.

DEADBOLTS

Deadbolts are 19mm, stainless steel.

SPRINGS

High-grade spring steel material, corrosion protected.

CYLINDER RETAINING PIN

Hard-drawn spring steel wire, corrosion protected.

DOOR THICKNESS

32mm to 50mmLocksets to suit thicker doors are available on application.

DOOR CLEARANCE

To ensure correct functioning of the deadlatching mechanism and security for all locks, the clearance between the door and the frame should be 3mm. However the deadlatching will operate up to 8mm door clearance.

ALUMINIUM DOORS

Aluminium door accessory packs and aluminium fix locks are available upon request. Specify SP3570-419 for mounting tabs accessory pack or 3572AFSC.

SECURITY

All 3570 Series Cylinder Mortice Locks conform to Level S2 (Physical Security) Australian Lock Standard (AS-4145.2-1993). Level S3 (Physical Security) is available upon request.

DURABILITY

All 3570 Series Cylinder Mortice Locks conform to level D3 (Durability) Australian Lock Standard (AS 4145.2- 1993).

FIRE RATING

Lockwood 3570 Series Mortice Locks have been successfully tested up to 4 hours (depending on type of door set) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

CYLINDER

5-pin tumbler mechanism. Standard Lockwood oval shaped brass cylinders and brass barrels.
Functions require the use of different cams and adaptors.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

EXTENDED CYLINDERS

Extended cylinders are available for thicker doors.

REBATE

Rebate kits to suit 13mm standard rebate are available.

ELECTRIC STRIKES

Lockwood 3570 Series Mortice Locks are compatible with most electric strikes. Refer local sales office for further details.

DOWNLOADABLE CONTENT

LOCKWOOD PENTAGON™ 3P72 UNIVERSAL LOCKS—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD PENTAGON™ 3P72 UNIVERSAL LOCKS

High security cylinder mortice locks and latches providing the latest in design and functionality. Suitable for heavy duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels and similar buildings. These locks have various latching functions, which can be operated by key or handle outside and by turnknob, key or handle inside. For ease of selection specify primary lock (3P72SS). This lock can then be easily adapted to suit function required without removing the lock from the door, by adjusting the Pentagon hub selector, and cylinder function selector. These locks have various latching functions, which can be operated by key or by a handle inside.

FEATURES AND BENEFITS OF THE PENTAGON 3P72 UNIVERSAL LOCKS

  • Ability to change lock function and handing without removing the lock from the door.
  • Easy in-door commissioning.
  • One universal cylinder cam performs all locking functions.
  • Australian designed and manufactured, the 3P70 Series Cylinder Mortice Locks are made from high quality materials to meet high durability and strength requirements. 35 degrees of lever rotation required to fully retract latch and auxiliary bolt. Elongated rose furniture fixing holes to accept 38 – 41mm screw pitch. Includes through-case fixing holes for cylinder and turnknob escutcheons.

STANDARDS

HIGH SECURITY

Conforms to level SL8 Australian Lock Standard (AS4145.2-2008) when fitted with door furniture and anti drill cylinder.

DURABILITY

Exceeds level D8 (Durability) Australian Lock Standard (AS4145.2-2008).

ANTI-CORROSION

All 3P70 Series locks meet C6 (168 hrs) Australian Lock Standard (AS4145.2-2008).

FIRE RATED

Lockwood 3P70 Series Mortice Locks have been successfully tested up to four hours (depending on type of door set) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

DOWNLOADABLE CONTENT

LOCKWOOD 3577 DUAL ENTRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 3577 DUAL ENTRY DEADLATCH

Suitable for heavy-duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels, and similar buildings.
3570 Series Cylinder Mortice Locks are made from quality materials to meet high durability and strength requirements.
Designed to enable emergency services to enter specific areas by second cylinder without giving access to all locksets in the building and the ability to lockout keys with restricted access at certain times.

FURNITURE

Select from Lockwood 1800, 2800 or Artefact Series II ranges.

CASE AND COVER PLATES

  • High purity zinc alloy material cases and stainless steel cover plates.
  • Brass plates provided for plated finishes available in square and round end.

BACKSET

  • 60mm standard backset.
  • Extended backsets 89 and 127mm are available on application.

LATCHBOLTS

Latchbolts are 15mm, stainless steel. Deadlatching is achieved by an auxiliary stainless steel latchbolt. This auxiliary bolt retracts when the main latchbolt is withdrawn when the door is closed.

DEADBOLTS

Deadbolts are 19mm, stainless steel.

SPRINGS

High-grade spring steel material, corrosion protected.

CYLINDER RETAINING PIN

Hard-drawn spring steel wire, corrosion protected.

DOOR THICKNESS

32mm to 50mmLocksets to suit thicker doors are available on application.

DOOR CLEARANCE

To ensure correct functioning of the deadlatching mechanism and security for all locks, the clearance between the door and the frame should be 3mm. However the deadlatching will operate up to 8mm door clearance.

ALUMINIUM DOORS

Aluminium door accessory packs and aluminium fix locks are available upon request. Specify SP3570-419 for mounting tabs accessory pack or 3572AFSC.

SECURITY

All 3570 Series Cylinder Mortice Locks conform to Level S2 (Physical Security) Australian Lock Standard (AS-4145.2-1993). Level S3 (Physical Security) is available upon request.

DURABILITY

All 3570 Series Cylinder Mortice Locks conform to level D3 (Durability) Australian Lock Standard (AS 4145.2- 1993).

FIRE RATING

Lockwood 3570 Series Mortice Locks have been successfully tested up to 4 hours (depending on type of door set) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

CYLINDER

5-pin tumbler mechanism. Standard Lockwood oval shaped brass cylinders and brass barrels.
Functions require the use of different cams and adaptors.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Brushed (SC)
  • Polished Brass (PB)

EXTENDED CYLINDERS

Extended cylinders are available for thicker doors.

REBATE

Rebate kits to suit 13mm standard rebate are available.

ELECTRIC STRIKES

Lockwood 3570 Series Mortice Locks are compatible with most electric strikes. Refer local sales office for further details.

DOWNLOADABLE CONTENT

LOCKWOOD 001 TOUCH™ ELECTRONIC DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 TOUCH™ ELECTRONIC DEADLATCH

For 30 years Lockwood’s iconic 001 has been securing homes in Australia. The 001 as we know it today has now become digital. As with the original product, the 001TOUCH™ uses the 001 Deadlatch to secure the door internally however, the external cylinder has been replaced with a stylish digital touch screen keypad. The ability to use a pin code or key card offers a convenient keyless solution.

KEY FEATURES OF THE 001TOUCH™ ELECTRONIC DEADLATCH

TOUCH SCREEN KEYPAD

The touch screen keypad has no mechanical buttons, which means no trace of your secret pin code.

4-12 DIGIT PIN CODE

Choose a pin code from 4 – 12 digits, this could be ideal for children or occupants that lose keys on a regular basis.

KEY CARDS

Program up to 20 key cards into your lock and have the ability to remove them individually.

TESTED IN ACCORDANCE WITH AS4145.2-2008

The 001TOUCH has been tested in accordance with the Australian lock standard.

SECURE MODE

You have the option to lock the 001TOUCH with the internal key, the key card and pin number automatically unlocks upon entry. This safety release function minimises the chance being locked inside your house.

LOW POWER CONSUMPTION

Unlock your door up to 10,000 times with one set of 4 x AA batteries. We recommend the batteries are changed every 12 months regardless.

OUTDOOR WEATHER RESISTANT KEYPAD

The keypad is designed to withstand most weather conditions.

MASTER CODE

You will have the ability as a master to add and delete users.

USER CODE THAT EXPIRES

You have the ability to program a code that may last from 3 – 366 hours. This is ideal when a tradesman requires access to your house for a few hours or when your neighbour is looking after your home for up to two weeks.

CRYPTIC CODE FUNCTION

Prevent others from identifying your pin code during access, the cryptic code function confuses the onlooker but at the same time allows you to still gain entry.

USER CODES AND SETTING REMAIN IF BATTERIES ARE REMOVED

The settings, codes and key cards will remain programmed in the lock in the event the batteries are depleted.

AUTOMATIC LOCKING

Once the correct code or key card is presented, the lock will remain unlocked for 5 seconds and will lock automatically when the 5 seconds expire.

VISUAL GUIDE FOR PROGRAMMING

For added convenience, a light guide will assist in the programming of some key features.
(Refer user guide.*)

DOWNLOADABLE CONTENT

LOCKWOOD 530 DIGITAL—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 530 DIGITAL DX ENTRANCE SET

The Lockwood Digital DX Locksets provide a mechanical method of keyless entry.
For extra security when under forced attack, the inbuilt clutching mechanism allows the outside knob to rotate without operating or damaging the lock.
The factory set 5-digit code is easily changed to any 4, 5 or 6 digit code using the code changing kit provided with each lock.
Lockwood Digital DX Locksets are designed to control access into commercial areas, especially when frequent combination changes are needed to maintain security.
As the digital lockset utilises mechanical operation, electrical wiring is not required. Selected locksets combined with digital access pads provide keyless entry.

FEATURES

  • Outside: Press the C button, enter the correct code, then turn the knob to unlock the door.
  • Upon releasing the turn knob the code is automatically cancelled.
    Inside: Opened by knob/lever at all times.

DOOR THICKNESS

32 to 45mm.

INTERNAL CASE ASSEMBLY

High purity zinc alloy, 92mm wide, 72mm high, 54mm projection.

LATCH

18mm projection, stainless steel.

BACKSET

60mm. 70 and 127mm latches available separately on application.
Options: Also available in double keypad version, which provides a keypad on each side of the door.
For product availability please contact customer service or your local sales office.

STANDARD FINISHES

  • Satin Chrome Pearl (SP)
  • Gold (GLD)

FIRE RATING

Lockwood 530 Digital DX Entrance Set (excluding rubber gasket) has been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS 1905.1: 1997, Fire Resistant Doorsets.

DOWNLOADABLE CONTENT

LOCKWOOD 002 DIGITAL —Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 002 DIGITAL DX DEADLATCH SC

The Lockwood Digital DX Locksets provide a mechanical method of keyless entry.
For extra security when under forced attack, the inbuilt clutching mechanism allows the outside knob to rotate without operating or damaging the lock.
The factory set 5-digit code is easily changed to any 4, 5 or 6 digit code using the code changing kit provided with each lock.
Lockwood Digital DX Locksets are designed to control access into commercial areas, especially when frequent combination changes are needed to maintain security.
As the digital lockset utilises mechanical operation, electrical wiring is not required. Selected locksets combined with digital access pads provide keyless entry.

SUITABILITY

  • Suits right- or left-hand doors opening in.
  • For outward opening doors or doors with metal frames, special 002 Digital DX Locks are available on application.

FEATURES

  • Outside: Press the C button, enter the correct code, then turn the knob to unlock the door.
  • Upon releasing the turn knob the code is automatically cancelled.
    Inside: Opened by knob/lever at all times.

DOOR THICKNESS

32 to 45mm.

INTERNAL CASE ASSEMBLY

High purity zinc alloy, 92mm wide, 72mm high, 54mm projection.

LATCH

18mm projection, stainless steel.

BACKSET

60mm.

HOLD-BACK FUNCTION

Bolt hold-back function activated by rotating inside knob/lever clockwise, past 90 degrees.

STANDARD FINISHES

  • Satin Chrome Pearl (SP)
  • Gold (GLD)

DOWNLOADABLE CONTENT

LOCKWOOD 002 DIGITAL —Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 2516DASIL CAM ACTION DOOR CLOSER

The Lockwood Digital DX Locksets provide a mechanical method of keyless entry. For extra security when under forced attack, the inbuilt clutching mechanism allows the outside knob to rotate without operating or damaging the lock.
The factory set 5-digit code is easily changed to any 4, 5 or 6 digit code using the code changing kit provided with each lock.
Lockwood Digital DX Locksets are designed to control access into commercial areas, especially when frequent combination changes are needed to maintain security.
As the digital lockset utilises mechanical operation, electrical wiring is not required. Selected locksets combined with digital access pads provide keyless entry.

SUITABILITY

  • Suits right- or left-hand doors opening in.
  • For outward opening doors or doors with metal frames, special 002 Digital DX Locks are available on application.

FEATURES

  • Outside: Press the C button, enter the correct code, then turn the knob to unlock the door.
  • Upon releasing the turn knob the code is automatically cancelled.
    Inside: Opened by knob/lever at all times.

DOOR THICKNESS

32 to 45mm.

INTERNAL CASE ASSEMBLY

High purity zinc alloy, 92mm wide, 72mm high, 54mm projection.

LATCH

18mm projection, stainless steel.

BACKSET

60mm.

HOLD-BACK FUNCTION

Bolt hold-back function activated by rotating inside knob/lever clockwise, past 90 degrees.

STANDARD FINISHES

  • Satin Chrome Pearl (SP)
  • Gold (GLD)

DOWNLOADABLE CONTENT

LOCKWOOD 530 DIGITAL—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 2516DASIL CAM ACTION DOOR CLOSER

The Lockwood Digital DX Locksets provide a mechanical method of keyless entry. For extra security when under forced attack, the inbuilt clutching mechanism allows the outside knob to rotate without operating or damaging the lock.
The factory set 5-digit code is easily changed to any 4, 5 or 6 digit code using the code changing kit provided with each lock.
Lockwood Digital DX Locksets are designed to control access into commercial areas, especially when frequent combination changes are needed to maintain security.
As the digital lockset utilises mechanical operation, electrical wiring is not required. Selected locksets combined with digital access pads provide keyless entry.

FEATURES

  • Outside: Press the C button, enter the correct code, then turn the knob to unlock the door.
  • Upon releasing the turn knob the code is automatically cancelled.
    Inside: Opened by knob at all times.

DOOR THICKNESS

35 to 45mm.

BACKSET

60mm.
70 and 127mm latches available separately on application.
Options: Also available in double keypad version, which provides a keypad on each side of the door.
For product availability please contact customer service or your local sales office.

STANDARD FINISHES

  • Satin Chrome Pearl (SP)
  • Polished Brass (PB)

FIRE RATING

Lockwood 530 Digital DX Entrance Set (excluding rubber gasket) has been successfully tested to 2 hours on fire door assemblies in accordance with Australian Standard AS 1905.1: 1997, Fire Resistant Doorsets.

DOWNLOADABLE CONTENT

LOCKWOOD 2514SIL CAM—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 2516DASIL CAM ACTION DOOR CLOSER

The Lockwood 2516 CAM Action Door Closer is a premium, high quality door-closing device. When opening a door fitted with a Lockwood 2516 CAM Action Door Closer, the force required is less than that of a rack and pinion type door closer and continues to decrease through the opening arc.
This aesthetically appealing, narrow profile CAM Action Door Closer is suited for public and commercial applications where children, the elderly and the disabled are likely to be using the door. For disabled toilet applications where a breakout feature is required, the double action of the mechanism allows the door to be operated in the opposite direction for easy access into the room.
The Lockwood 2516 is light to open, but its adjustable closing force is high enough for heavy duty applications. The 2516 is non-handed and therefore very easy to install – either on the inside of the door or on the doorframe.

FEATURES

  • Adjustable spring power from size EN 1 to 4.
  • Cushioned back check (BC) 2516-153 – for fire door applications.
  • Easily adjustable arm height.
  • Adjustable closing speed.
  • Adjustable latching speed.
  • Hold open 2516-152.
  • Cast aluminium body manufactured from high-performance silicon alloy.
  • Two pressure relief valves are a standard feature to protect against abuse.
  • High efficiency: 70 – 80%.
The Lockwood 2514 CAM Action Door Closer has successfully been fire rated on fire door assemblies in accordance with Australian Standard AS 1905.1 – 2005: Fire-resistant door sets.

SUITABILITY

  • Hinged interior and exterior doors.
  • Opening in or opening out doors.
  • Fire doors.
  • Timber doors.
  • Aluminium framed doors.

Standard finishes

  • Satin stainless steel (SSS)
  • Polished Brass (PB)
  • Silver (SIL)
  • One Model (2514): Coversmost applications.
  • Right hand and left hand applications and pullside/ push side applications.

PART NUMBERS

  • Satin Stainless Steel 2516DASSS
  • Gold Plated 2516DAPB
  • Silver 2516DASIL

DOWNLOADABLE CONTENT

INSTALLATION INSTRUCTIONS

LOCKWOOD 2514SIL CAM—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 100 NIGHTLATCH

The Lockwood 2514 Series is a non-handed CAM Action door closer. Due to the CAM design this premium door closer is light to open but still strong enough to close a door. The Lockwood 2514 door closer can be adjusted to meet the requirements of a light door opening resistance and is ideal for both interior and exterior doors.
The Lockwood 2514 Series is suitable for doors with a maximum door weight of 80kg and a door leaf width of 1100mm (sliding arm installation).

FEATURES

  • Adjustable spring power from size EN 1 to 4.
  • Cushioned back check (BC) 2516-153 – for fire door applications.
  • Easily adjustable arm height.
  • Adjustable closing speed.
  • Adjustable latching speed.
  • Hold open 2516-152.
  • Cast aluminium body manufactured from high-performance silicon alloy.
  • Two pressure relief valves are a standard feature to protect against abuse.
  • High efficiency: 70 – 80%.
The Lockwood 2514 CAM Action Door Closer has successfully been fire rated on fire door assemblies in accordance with Australian Standard AS 1905.1 – 2005: Fire-resistant door sets.

SUITABILITY

  • Hinged interior and exterior doors.
  • Opening in or opening out doors.
  • Fire doors.
  • Timber doors.
  • Aluminium framed doors.

Standard finishes

  • Satin stainless steel (SSS)
  • Silver (SIL)
  • One Model (2514): Coversmost applications.
  • Right hand and left hand applications and pullside/ push side applications.

PART NUMBERS

  • Satin Stainless Steel 2514SSS
  • Silver 2514SIL

DOWNLOADABLE CONTENT

INSTALLATION INSTRUCTIONS

LOCKWOOD 201 NIGHTLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 100 NIGHTLATCH

General purpose nightlatch.

FEATURES

  • Opened by key from outside and by turn knob inside.
  • Bolt may be held back by turning knob in clockwise direction.

CASE

High purity zinc alloy.
92mm wide, 64mm high, 43mm projection.

BACKSET

60mm.

LATCH

  • Brass.
  • Reversible.
  • 13mm projection.

DOOR THICKNESS

28 to 45mm.

DOWNLOADABLE CONTENT

LOCKWOOD 201 NIGHTLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 201 NIGHTLATCH

A general purpose nightlatch with inside snib.

FEATURES

  • Opened by key from outside and by turn knob inside.
  • Inside snib may be used to hold-back or deadlock bolt so that key will not operate.

CASE

High purity zinc alloy.
92mm wide, 64mm high, 43mm projection.

BACKSET

60mm.

LATCH

  • Brass.
  • Reversible.
  • 13mm projection.

DOOR THICKNESS

28 to 45mm.

DOWNLOADABLE CONTENT

LOCKWOOD 509 SERIES NIGHTLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 509 SERIES NIGHTLATCH

Commercial grade nightlatch with inside snib designed for surface mounting on the inside of outward opening doors.

FEATURES

  • Inside snib may be used to hold-back latchbolt.
  • Steel case and strike.
  • Available with standard box strike (RBP model) or open out strike (RBS model).
  • Bolt hold-back function activated by snib.
  • Latchbolt operated by key from outside and by turn from inside.
  • Available in trade pack only.
  • Opened by key from outside and by turn knob from inside.

CASE

Steel.

BACKSET

60mm.

LATCH

Brass.

DOOR THICKNESS

32mm to 60mm

KEYING

Supplied less cylinder.

CYLINDER (SOLD SEPARATELY)

Lockwood 201 Cylinder.

FINISH

Satin Chrome Pearl (SP)

DOWNLOADABLE CONTENT

LOCKWOOD 002 SINGLE CYLINDER DEADLATCH SATIN PEARL—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 002 SINGLE CYLINDER DEADLATCH SATIN PEARL

The market leading 002 Deadlatch range from Lockwood offers exceptional performance and reliability for various applications.

FEATURES

  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and door frame strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be keyed alike to other Lockwood door locks.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • 5-pin tumbler mechanism outside.
  • Brass cylinder and barrel.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISH

Satin Chrome Pearl (SP)

DOWNLOADABLE CONTENT

LOCKWOOD 002 SINGLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 002 SINGLE CYLINDER DEADLATCH WITH LEVER SC

The market leading 002 Deadlatch range from Lockwood offers exceptional performance and reliability for various applications.

FEATURES

  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and door frame strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be keyed alike to other Lockwood door locks.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

BOLT

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

CYLINDERS

  • 5-pin tumbler mechanism outside.
  • Brass cylinder and barrel.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISH

Satin Chrome Pearl (SP)

DOWNLOADABLE CONTENT

LOCKWOOD 355 DEADLOCK SATIN CHROME—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 303 DEADLOCK SATIN CHROME

The security features provided by the 303 Deadlock make it an ideal lockset for both domestic and commercial applications.

FEATURES

  • Suitable for hinged and some sliding doors.
  • Lockable turn knob with inbuilt clutching device to resist wrench attack.
  • Strong interlocking case and mounting plate to resist jemmy and hammer attack.
  • Tested in accordance with AS4145.2-1993.
  • Concealed fixing.
  • Positive deadlocking action.
  • The mechanism and the design are protected by Australian and International Patents and Design Registrations.
  • Available in trade and display pack versions.
  • Opened by key from outside and by turn knob from inside when free. Internal key locks or unlocks turn knob.

CASE

  • Thick walled, high purity zinc alloy casting.
  • 121mm wide, 76mm high, 56mm projection.

BACKSET

60mm.

BOLT

Stainless steel.

MOUNTING PLATE AND STRIKE

Pressed steel.

CASE RETAINER PLATE AND OPERATING MECHANISM

  • Solid pressed steel and die cast.
  • Zinc components.

PACKING PLATES

3mm thick packing plates installed under lock body to align lock body with face of jamb.

STRIKE CONVERSION PLATE

A strike conversion plate is required where the strike is to be installed in place of an existing flange strike.

DOOR THICKNESS

30 – 45mm.

CYLINDERS

  • 5-pin tumbler mechanism outside.
  • Brass cylinder and barrel.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISH

Satin Chrome Pearl (SP)

DOWNLOADABLE CONTENT

LOCKWOOD 355 DEADLOCK SATIN CHROME—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 355 DEADLOCK SATIN CHROME

The premium security features provided by the 355 Deadlock make it an ideal lockset for both domestic and commercial applications.

FEATURES

  • Suitable for hinged and some sliding doors.
  • Lockable turn knob with inbuilt clutching device to resist wrench attack.
  • Strong interlocking case and mounting plate to resist jemmy and hammer attack.
  • Tested in accordance with AS4145.2-1993.
  • Concealed fixing.
  • Positive deadlocking action.
  • The mechanism and the design are protected by Australian and International Patents and Design Registrations.
  • Available in trade and display pack versions.
  • Opened by key from outside and by turn knob from inside when free. Internal key locks or unlocks turn knob.

CASE

Thick walled, high purity zinc alloy casting.

BACKSET

60mm.

BOLT

  • Stainless steel.
  • Mounting Plate and Strike
  • Pressed steel.
  • Case Retainer Plate and
  • Operating Mechanism
  • Solid pressed steel and die cast.
  • Zinc components.

PACKING PLATES

3mm thick packing plates installed under lock body to align lock body with face of jamb.

STRIKE CONVERSION PLATE

A strike conversion plate is required where the strike is to be installed in place of an existing flange strike.

DOOR THICKNESS

30 – 45mm.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 507 SERIES—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 507 SERIES NIGHTLATCH

Fire rated to 4 hours, making this the ideal lockset for a range of commercial applications – utility and service cupboards.

FEATURES

  • The Lockwood 507 Rim Nightlatch has been fire rated up to 4 hours on fire door assemblies in accordance with Australian standard AS 1905.1:1997, Part 1: Fire Resistant Doorsets.
  • Steel case, strike and latchbolt.
  • Designed for surface mounting on the inside of outward opening doors.
  • Available with standard box strike (RBP model) or open out strike (RBS model).
  • Latchbolt operated by key from outside and by turn from inside.
  • Available in trade pack only.
  • Opened by key from outside and by turn knob from inside.

CASE

Steel.

BACKSET

60mm.

LATCH

Steel.

DOOR THICKNESS

30 – 45mm.

KEYING

  • Supplied less cylinder.
  • Cylinder (sold separately)
  • Lockwood 201 Cylinder.
  • 5-pin tumbler mechanism.

FINISH

Satin Chrome Pearl (SP)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER OPEN OUT DEADLATCH SCP WITH LEVER

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™.

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER METAL FRAME DEADLATCH SATIN CHROME PEARL WITH LEVER

The Lockwood 001 Deadlatch with LockAlert� status indicator and Safety Release™.

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH SATIN CHROME PEARL WITH LEVER

The Lockwood 001 Deadlatch with LockAlert� status indicator and Safety Release™.

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH GOLD

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER METAL FRAME DEADLATCH SATIN CHROME PEARL

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH SATIN CHROME PEARL

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH SATIN CHROME PEARL

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 001 DOUBLE CYLINDER DEADLATCH CHROME PLATE

The Lockwood 001 Deadlatch with LockAlert status indicator and Safety Release™

FEATURES

  • The unique LockAlert status indicator shows the lockset status at a glance.
  • Safety Release automatically unlocks the internal knob upon entry.
  • High security with cut resistant stainless steel bolt, 11 concealed anchorage points and doorframe strengthener.
  • Tested in accordance with AS4145.2 – 1993.
  • Bolt hold-back function activated by external key or internal knob.
  • Can be key locked in hold-back position by key from inside.
  • Can be keyed alike to other Lockwood door locks.
  • Available in trade and display pack versions.

CASE

High purity zinc alloy.

BACKSET

60mm.

LATCH

Stainless steel 18mm projection.

DOOR THICKNESS

30 – 45mm.

PACKERS

3mm thick packer plates are available; these packers are installed under lock body to align lock body with face of jamb.

CYLINDERS

  • Internal and external 5-pin tumbler mechanism.
  • Brass cylinders and brass barrels.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

FINISHES

  • Gold (GLD)
  • Satin Chrome Pearl (SP)
  • Chrome Plate (CP)
  • Brown (BRN)

DOWNLOADABLE CONTENT

YALE DOUBLE CYLINDER DEADBOLT—Locksmiths & Electronics in Tweed Heads NSW

YALE DOUBLE CYLINDER DEADBOLT

  • Suits hinged doors 35-45mm thick.
  • Suitable for timber and metal frame doors.
  • Ease of retrofit to existing doors as a replacement.
  • Latch is adjustable for 60-70mm backset.
  • Double cylinder lock for added security.
  • Yale Keyway.
  • Can be keyed alike to other Yale products.
  • Designed to Yale quality and performance standards.

FINISHES

  • Chrome Plate.
  • Satin Chrome.

KEYING

Yale profile.

NO. OF KEYS

3 nickel plated keys.

BACKSET

  • Adjustable 60mm – 70mm.

DOOR THICKNESS

35mm – 45mm (suitable for timber and metal frame doors).

STANDARDS

ANSI – The Yale Rimlocks and Borelocks meet the American National Standard for Bored and Preassembled Locks and Latches to a Grade 3 Level (ANSI/BHMA A156.2-2003).

DOWNLOADABLE CONTENT

YALE DOUBLE CYLINDER DEADBOLT—Locksmiths & Electronics in Tweed Heads NSW

YALE SINGLE CYLINDER DEADBOLT

  • Suits hinged doors 35-45mm thick.
  • Suitable for timber and metal frame doors.
  • Ease of retrofit to existing doors as a replacement.
  • Latch is adjustable for 60-70mm backset.
  • Inside turn knob for ease of egress.
  • Yale Keyway.
  • Can be keyed alike to other Yale products.
  • Designed to Yale quality and performance standards.

FINISHES

  • Chrome Plate.
  • Satin Chrome.

KEYING

Yale profile.

NO. OF KEYS

3 nickel plated keys.

BACKSET

  • Adjustable 60mm – 70mm.

DOOR THICKNESS

35mm – 45mm (suitable for timber and metal frame doors).

STANDARDS

ANSI – The Yale Rimlocks and Borelocks meet the American National Standard for Bored and Preassembled Locks and Latches to a Grade 3 Level (ANSI/BHMA A156.2-2003).

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY DOUBLE CYLINDER DEADBOLT SATIN STAINLESS STEEL

  • General purpose double cylinder deadbolt recommended for use with Symmetry knob and lever locksets.
  • Operated by key from both inside and outside.
  • Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt.

CYLINDER

  • The one cylinder assembly solution “OneCyl” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying
  • Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • EverBrass (EVB)
  • Polished Stainless Steel (PSS)
  • Satin Stainless Steel (SSS)

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY DOUBLE CYLINDER DEADBOLT SATIN STAINLESS STEEL

  • General purpose double cylinder deadbolt recommended for use with Symmetry knob and lever locksets.
  • Operated by key from both inside and outside.
  • Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt.

CYLINDER

  • The one cylinder assembly solution “OneCyl�” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying
  • Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • EverBrass (EVB)
  • Polished Stainless Steel (PSS)
  • Satin Stainless Steel (SSS)

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY DOUBLE CYLINDER DEADBOLT POLISHED SATIN STEEL

  • General purpose double cylinder deadbolt recommended for use with Symmetry knob and lever locksets.
  • Operated by key from both inside and outside.
  • Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt.

CYLINDER

  • The one cylinder assembly solution “OneCyl�” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying
  • Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • EverBrass (EVB)
  • Polished Stainless Steel (PSS)
  • Satin Stainless Steel (SSS)

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY DOUBLE CYLINDER DEADBOLT EVERBRASS

  • General purpose double cylinder deadbolt recommended for use with Symmetry knob and lever locksets.
  • Operated by key from both inside and outside.
  • Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt.

CYLINDER

  • The one cylinder assembly solution “OneCyl�” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

EverBrass (EVB) Polished Stainless Steel (PSS) Satin Stainless Steel (SSS)

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY SINGLE CYLINDER DEADBOLT SATIN STAINLESS STEEL

  • General purpose single cylinder deadbolt.
  • Operated by key from outside and turn knob inside. Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt cylinder.

CYLINDER

  • The one cylinder assembly solution “OneCyl�” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass cylinder assembly (6-pin compatible).
    Also available with “PD” type cylinder in stainless steel finish (part number 7105SSS) for compatibility with a broader range of restricted keying systems.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying
  • Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Polished Brass (PB)
  • Polished Stainless Steel (PSS)
  • Satin Stainless Steel (SSS)
  • Satin Chrome Brushed (SC)

DOWNLOADABLE CONTENT

LOCKWOOD SYMMETRY—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD SYMMETRY SINGLE CYLINDER DEADBOLT POLISHED BRASS

  • General purpose single cylinder deadbolt.
  • Operated by key from outside and turn knob inside. Suits left or right hand opening doors.
  • Solid brass bolt with 25mm projection.
  • Hardened insert in locking bolt cylinder.

CYLINDER

  • The one cylinder assembly solution “OneCyl�” has been designed for the Lockwood Symmetry Range, which grants the convenience of cylinder interchangeability.
  • 5-pin Lockwood C4 brass cylinder assembly (6-pin compatible).
    Also available with “PD” type cylinder in stainless steel finish (part number 7105SSS) for compatibility with a broader range of restricted keying systems.

BACKSET

Adjustable 60 – 70mm bolt.

DOOR THICKNESS

30* to 50mm.* Requires spacer ring (included).

KEYING

  • Standard Keying
  • Supplied individually keyed with three keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

STANDARD FINISHES

  • Polished Brass (PB)
  • Polished Stainless Steel (PSS)
  • Satin Stainless Steel (SSS)
  • Satin Chrome Brushed (SC)

DOWNLOADABLE CONTENT

LOCKWOOD 005 PARADIGM—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 005 PARADIGM DEADBOLT SQUARE CHROME PLATE

Designed in Australia, the Paradigm 005 Deadbolt range represents the pinnacle in deadbolt security products. Incorporating innovative safety features including Safety Release™, LockAlert and DualSelect, the Paradigm range is ideal for residential and architectural applications.

FEATURES

  • Multi-mode slimline deadbolt providing safety, security and convenience.
  • Simple to install.
  • Advanced safety and features.
  • High security cut resistant stainless steel bolt.
  • Available in round and square designs.
  • Box strike with concealed crossgrain doorframe strengthening screw.
  • Meets highest security and durability requirements in AS4145.2 – 1993 Locksets.
  • Adjustable 60mm – 70mm backset.
  • Fits standard door preparation – 54mm diameter crossbore hole.
  • Can be keyed alike to other Lockwood door locks.

COUNTERBALANCE BOLT

The Paradigm 005 Deadbolt has been designed to achieve the highest possible Australian Standard door lock security rating via the Counterbalance Bolt, which proportionally distributes the load between the door and door frame.

DUALSELECT LOCKING

  • DualSelect Introduces two stage external locking – safety mode and secure mode.
  • By rotating the key 90? the bolt can be thrown achieving external security whilst the internal turn knob is free to exit (Safety Mode).
  • By rotating the key a further 45? to the second click, the bolt will now be secure on both sides of the door (Secure Mode).

SAFETY RELEASE™

Safety Release automatically unlocks the internal knob upon entry. This minimises the risk of being locked inside in the case of an emergency.

LOCKALERT

The Paradigm 005 Deadbolt incorporates Lockwood’s patented LockAlert status indicator that shows the lockset mode at a glance. The lockset can operate in three modes: Secure Mode, Safety Mode and Passage Mode.

BACKSET

60 to 70mm adjustable stainless steel bolt.

DOOR THICKNESS

32 – 48mm. However, 32 – 36mm doors require spacer ring (included).

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Pearl (SP)
  • Satin Chrome Brushed (SC)
  • Gold (GLD)
  • Satin Stainless Steel (SSS)*

MATERIALS

High purity zinc alloy

*Stainless steel version features 304 grade satin stainless steel rose, turn knob and trim.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

SECURITY

Paradigm 005 Deadbolt conforms to level S3 (Physical Security) Australian Lock Standard (AS 4145.2: 1993).

DURABILITY

Paradigm 005 Deadbolt conforms to level D3 (Durability) Australian Lock Standard (AS 4145.2: 1993).

ANTI-CORROSION

This product has been successfully tested in accordance with AS2332.3.1:2001. Neutral Salt Spray Test (NSS TEST).
Available in stainless steel for increased corrosion resistance.

DOWNLOADABLE CONTENT

LOCKWOOD 005 PARADIGM—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 005 PARADIGM DEADBOLT SQUARE GOLD

Designed in Australia, the Paradigm 005 Deadbolt range represents the pinnacle in deadbolt security products. Incorporating innovative safety features including Safety Release™, LockAlert and DualSelect, the Paradigm range is ideal for residential and architectural applications.

FEATURES

  • Multi-mode slimline deadbolt providing safety, security and convenience.
  • Simple to install.
  • Advanced safety and features.
  • High security cut resistant stainless steel bolt.
  • Available in round and square designs.
  • Box strike with concealed crossgrain doorframe strengthening screw.
  • Meets highest security and durability requirements in AS4145.2 – 1993 Locksets.
  • Adjustable 60mm – 70mm backset.
  • Fits standard door preparation – 54mm diameter crossbore hole.
  • Can be keyed alike to other Lockwood door locks.

COUNTERBALANCE BOLT

The Paradigm 005 Deadbolt has been designed to achieve the highest possible Australian Standard door lock security rating via the Counterbalance Bolt, which proportionally distributes the load between the door and door frame.

DUALSELECT LOCKING

  • DualSelect Introduces two stage external locking – safety mode and secure mode.
  • By rotating the key 90? the bolt can be thrown achieving external security whilst the internal turn knob is free to exit (Safety Mode).
  • By rotating the key a further 45? to the second click, the bolt will now be secure on both sides of the door (Secure Mode).

SAFETY RELEASE™

Safety Release automatically unlocks the internal knob upon entry. This minimises the risk of being locked inside in the case of an emergency.

LOCKALERT

The Paradigm 005 Deadbolt incorporates Lockwood’s patented LockAlert status indicator that shows the lockset mode at a glance. The lockset can operate in three modes: Secure Mode, Safety Mode and Passage Mode.

BACKSET

60 to 70mm adjustable stainless steel bolt.

DOOR THICKNESS

32 – 48mm. However, 32 – 36mm doors require spacer ring (included).

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Pearl (SP)
  • Satin Chrome Brushed (SC)
  • Gold (GLD)
  • Satin Stainless Steel (SSS)*

MATERIALS

High purity zinc alloy

*Stainless steel version features 304 grade satin stainless steel rose, turn knob and trim.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

SECURITY

Paradigm 005 Deadbolt conforms to level S3 (Physical Security) Australian Lock Standard (AS 4145.2: 1993).

DURABILITY

Paradigm 005 Deadbolt conforms to level D3 (Durability) Australian Lock Standard (AS 4145.2: 1993).

ANTI-CORROSION

This product has been successfully tested in accordance with AS2332.3.1:2001. Neutral Salt Spray Test (NSS TEST).
Available in stainless steel for increased corrosion resistance.

DOWNLOADABLE CONTENT

LOCKWOOD 005 PARADIGM—Locksmiths & Electronics in Tweed Heads NSW

LOCKWOOD 005 PARADIGM DEADBOLT SQUARE GOLD

Designed in Australia, the Paradigm 005 Deadbolt range represents the pinnacle in deadbolt security products. Incorporating innovative safety features including Safety Release™, LockAlert and DualSelect, the Paradigm range is ideal for residential and architectural applications.

FEATURES

  • Multi-mode slimline deadbolt providing safety, security and convenience.
  • Simple to install.
  • Advanced safety and features.
  • High security cut resistant stainless steel bolt.
  • Available in round and square designs.
  • Box strike with concealed crossgrain doorframe strengthening screw.
  • Meets highest security and durability requirements in AS4145.2 – 1993 Locksets.
  • Adjustable 60mm – 70mm backset.
  • Fits standard door preparation – 54mm diameter crossbore hole.

COUNTERBALANCE BOLT

The Paradigm 005 Deadbolt has been designed to achieve the highest possible Australian Standard door lock security rating via the Counterbalance Bolt, which proportionally distributes the load between the door and door frame.

DUALSELECT LOCKING

  • DualSelect Introduces two stage external locking – safety mode and secure mode.
  • By rotating the key 90? the bolt can be thrown achieving external security whilst the internal turn knob is free to exit (Safety Mode).
  • By rotating the key a further 45? to the second click, the bolt will now be secure on both sides of the door (Secure Mode).

SAFETY RELEASE™

Safety Release automatically unlocks the internal knob upon entry. This minimises the risk of being locked inside in the case of an emergency.

LOCKALERT

The Paradigm 005 Deadbolt incorporates Lockwood’s patented LockAlert status indicator that shows the lockset mode at a glance. The lockset can operate in three modes: Secure Mode, Safety Mode and Passage Mode.

BACKSET

60 to 70mm adjustable stainless steel bolt.

DOOR THICKNESS

32 – 48mm. However, 32 – 36mm doors require spacer ring (included).

CYLINDER

  • 5-pin tumbler mechanism.
  • Brass cylinder and brass barrel.

STANDARD FINISHES

  • Chrome Plate (CP)
  • Satin Chrome Pearl (SP)
  • Satin Chrome Brushed (SC)
  • Gold (GLD)
  • Satin Stainless Steel (SSS)*

MATERIALS

High purity zinc alloy

*Stainless steel version features 304 grade satin stainless steel rose, turn knob and trim.

KEYING

  • Standard Keying
  • Supplied individually keyed with two keys per lock.
  • 78,000 key combinations.
  • Key blank KB2015P.
  • Restricted Special Keying
  • Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

SECURITY

Paradigm 005 Deadbolt conforms to level S3 (Physical Security) Australian Lock Standard (AS 4145.2: 1993).

DURABILITY

Paradigm 005 Deadbolt conforms to level D3 (Durability) Australian Lock Standard (AS 4145.2: 1993).

ANTI-CORROSION

This product has been successfully tested in accordance with AS2332.3.1:2001. Neutral Salt Spray Test (NSS TEST).
Available in stainless steel for increased corrosion resistance.

DOWNLOADABLE CONTENT
